B-2 Measurement Overview Measurement Review
If the system does not meet specification, then line sweeping can also locate
components that are reflecting power above specified levels.
Figure B-1. Cable and Antenna Line Sweeping
Note
The Site Master does not measure system linearity (PIM Testing).
Anritsu also sells the PIM Master, which is available in several
carrier bands. The PIM Master tests for passive inter-modulation.
