2. WITH CONNECTOR DISCONNECTED (4-ways black, inside the bow) CHECK IF
THERE IS GROUND CONNECTION ON PIN 3, ON THE CABLE HARNESS SIDE
YES, go to 3; NO, go to 6
•
3. CHECK WITH CONNECTOR DISCONNECTED (4-ways black, inside the bow) ON THE
SWITCH SIDE, PUSHING THE SWITCH, IF THERE IS CONTINUITY BETWEEN PIN 2
AND PIN 3
YES, go to 4; NO, go to 7
•
4. REPLACE THE CONTROL UNIT - END
•
5. CHECK CONTINUITY OF PINK CABLE BETWEEN SWITCH CONNECTOR AND PIN
58 OF THE CONTROL UNIT, CHECKING ALSO THE ENGINE - VEHICLE CABLE HAR-
NESS CONNECTOR
YES, go to 4; NO, restore the cable harness - END
•
6. CHECK CONTINUITY OF PINK/BLACK CABLE BETWEEN SWITCH CONNECTOR
AND PIN 4 OF THE CONTROL UNIT, CHECKING ALSO THE ENGINE - VEHICLE CABLE
HARNESS CONNECTOR
YES, go to 4; NO, restore the cable harness - END
•
7. REPLACE THE STARTER BUTTON COMPONENT - END
RSV4 R Troubleshooting
TROUBL - 91
