Bosch Rexroth OptiFeed-FS EcoDrive 03 FLP04VRS - N111 Function of Output Channel 1; N119 Reserved; N120 Reserved

ECODRIVE03-FL*-04VRS Parameters 9-67
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
N111 Function of Output Channel 1
1 00 00 000
Timer Run Time
Switch Off Lead Time in ms
Switch On Lead Time in ms
Output Function
0 = Output 1 off
1 = Output 1 on
2 = Output 1 set as timer
Output Function:
The output function determines whether or not the output is used,
and how it is used.
Lead Time:
To balance switching hystereses for connected peripherals, a
lead time for turning on/off the output can be set. Depending on
the encoder speed, the corresponding output is turned on/off
earlier.
Run Time:
If the output is programmed as a timer, it is set when the PLS
position is reached and cleared again after the programmed time
has expired.
Note: Parameters N112 – N118 have the same function for
output channels 2 through 8.
N119 Reserved
N120 Reserved
