C
HAPTER
2
| Initial Switch Configuration
Basic Configuration
– 44 –
CONFIGURING ACCESS FOR SNMP VERSION 3 CLIENTS
To configure management access for SNMPv3 clients, you need to first
create a user, assign the user to a group, create a view that defines the
portions of MIB that the client can read or write, and then create an access
entry with the group and view. The following example creates a user called
Steve, indicating that MD5 will be used for authentication, and provides the
passwords for both authentication and encryption. It assigns this user to a
group called “r&d.” It then creates one view called “mib-2” that includes
the entire MIB-2 tree branch, and another view that includes the IEEE
802.1d bridge MIB. In the last step, it assigns these respective read and
read/write views to the group called “r&d.”
>snmp user add 800007e5017f000001 steve md5 greenearth des blueseas
>snmp group add usm steve r&d
>snmp view add mib-2 included .1.3.6.1.2.1
>snmp view add 802.1d included .1.3.6.1.2.1.17
>snmp access add r&d usm noauthnopriv mib-2 802.1d
>snmp configuration
.
.
.
SNMPv3 Users Table:
Idx Engine ID User Name Level Auth Priv
--- --------- -------------------------------- -------------- ---- ----
1 Local default_user NoAuth, NoPriv None None
2 Local steve Auth, Priv MD5 DES
.
.
.
SNMPv3 Groups Table;
Idx Model Security Name Group Name
--- ----- -------------------------------- --------------------------------
1 v1 public default_ro_group
2 v1 private default_rw_group
3 v2c public default_ro_group
4 v2c private default_rw_group
5 usm default_user default_rw_group
6 usm steve r&d
.
.
.
SNMPv3 Views Table:
Idx View Name View Type OID Subtree
--- -------------------------------- --------- ------------------------------
1 default_view included .1
2 mib-2 included .1.3.6.1.2.1
3 802.1d included .1.3.6.1.2.1.17
.
.
.
For a more detailed explanation on how to configure the switch for access
from SNMP v3 clients, refer to “Simple Network Management Protocol” on
page 130, or refer to the specific CLI commands for SNMP starting on
page 335.
