Stress Echo
LOGIQ 7 Basic User Manual 10-93
Direction 2392206-100 Rev. 1
Starting acquisition (continued)
If the Protocol tab is selected during acquisiton, the following
Touch Panel displays.
Figure 10-10. Protocol Tab during acquisition
Stop Stop Stress Echo.
Pause Pause Stress Echo. The template matrix continues
in display. Even if you press P1, the cine loop does
not store to the matrix.
Select Cycles The Continuous Capture Selection screen is
displayed (only available in Continuous Capture
mode).
Analyze Enter Analysis screen.
Template Enter Template screen.
Add Level Add level to the template.
T2 Display (Start)/Hide Timer T2.
