Vascular
11-28 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
To edit a worksheet (continued)
To exclude data:
When the user selects a particular value on the Worksheet and
select Exclude Value, this value is excluded from result line and
resultant value is re-calculated without this value and also
calculation values using this value is ‘blank’.
1. Select Worksheet Display from any page of the Vascular
Calculation Touch Panel Menu.
2. To position the cursor at the field you want to delete or
exclude, move the Trackball.
The field is highlighted.
3. Select Exclude Value.
4. The data in the field is not visible and is not included in
worksheet calculations as below.
5. To include a value that you previously excluded, select
Exclude Value.
Figure 11-15. Display of the excluded value
