Custom Report Pages
LOGIQ 7 Basic User Manual 14-27
Direction 2392206-100 Rev. 1
Measurements Display Fields
Insert a field for the display of the measurements made. The
measured parameters displayed in the measurement display
field are configured.
1. Insert a table for the Measurement Display to the desired
location.
2. Move the cursor to the table and press Set.
3. Move the cursor to the Customize menu and select
Measurements. Press Set.
4. The Measurements Box displays.
Figure 14-24. Measurement Box
5. Enter the Heading text, select the Filter Criteria and
measurements from the tree, as necessary.
6. Select OK or Cancel.
