Preparing for a Biopsy
LOGIQ 7 Online Help 17-33
Direction 2392536-100 Rev. 1
Fixed Needle Guide Assembly (continued)
Snap the fixed or adjustable needle clip onto the biopsy guide
bracket.
Figure 17-11. Fixed Needle Clip Attachment
1. Sheath
Choose the desired gauge (size) needle barrel. Twist it back
and forth to remove it from the plastic tree.
Figure 17-12. Needle Barrels
1
