Probes and Biopsy
17-34 LOGIQ 7 Online Help
Direction 2392536-100 Rev. 1
Fixed Needle Guide Assembly (continued)
Place the needle barrel into the needle clip with the desired
gauge facing the needle clip and snap into place.
Figure 17-13. Needle Barrel Installation
CAUTION
Ensure that all guide parts are seated properly prior to
perfoming a biopsy.
