User Maintenance
18-14 LOGIQ 7 Online Help
Direction 2392536-100 Rev. 1
Discs
To clean the discs:
• If the disc is dirty, you can clean it with a commercially
available dust removal spray. Be careful not to scratch the
disc when wiping it off.
NOTE: CD type cleaner cannot be used.
Trackball
1. Power off the system.
2. Place your fingers onto the notches of the Trackball retainer
ring.
3. Rotate the retainer ring counterclockwise until it can be
removed from the keyboard.
Figure 18-1. Rotating the Retainer Ring
a. Retainer Ring
HINTS
Keeping your media disc in an original media case or caddy all
the time will prevent it from becoming dirty or damaged.
(a)
