3-12-2 Hospital Network Connection to EchoPAC PC Workstation
See the EchoPAC PC Service Manual, Direction Number EP091298, for details about EchoPAC PC,
and its set-up.
Figure 3-146 Hospital Network Connections
Using standard non-crossed cables and MDI
switch set to position =HUB, connect like this.
Wall connection
EchoPAC PC
Network
Printer
Vivid 3
or Vivid 7
To Next Page
