GE Vivid 7 - Video Specifications

GE HEALTHCARE
DIRECTION FC091194, REVISION 11 VIVID 7 SERVICE MANUAL
5 - 122 Section 5-8 - External I/O
5-8-9 Video Specifications
5-8-9-1 PAL Video Specifications
5-8-9-2 NTSC Video Specifications
5-8-9-3 SVGA
Table 5-82 PAL Video Specifications
HORIZONTAL TIMING
Horizontal Total (HT) 64 µs 944 pixels
Horizontal Start (HS) 10.3051 µs 152 pixels
Horizontal Active (HA) 52 µs 768 pixels
Pixel Clock Freq. 14.7 MHz (PAL)
VERTICAL TIMING (INTERLACED)
Vertical Start (VS) 53 Lines / field
Active Lines (VA) 576 Lines / frame (=PAL standard)
Total Lines (VT) 625 Lines / frame (=PAL standard)
Frame Rate 25 Hz (=PAL standard)
Table 5-83 NTSC Video Specifications
HORIZONTAL TIMING
Horizontal Total (HT) 63.556 µs 780 pixels
Horizontal Start (HS) 9.6149 µs 118 pixels
Horizontal Active (HA) 52.6555 µs 640 pixels
Pixel Clock Freq. 12.272725 MHz (NTSC)
VERTICAL TIMING (INTERLACED)
Vertical Start (VS) 17 Lines / field
Active Lines (VA) 486 Lines / frame
(=NTSC standard)
Total Lines (VT) 525 Lines / frame
(=NTSC standard)
Frame Rate 29.97 Hz
(=NTSC standard)
Table 5-84 SVGA Video Specifications
STANDARD FORMAT SIGNAL SYNC DDC TERMINATION
SVGA
800 x 600 / 75 Hz
RGB: 0-700 mV
H: TTL
V: TTL
VESA DDC2
signals
75 ohms
