GE HEALTHCARE
DIRECTION FC091194, REVISION 11 VIVID 7 SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5 - 143
5-12-3 Location in the Unit
Figure 5-94 Top Console, upper positions
Figure 5-95 Release Handles location (below the Top Console)
Operator Panel
Extended Frogleg
Flexible harness
Monitor
Monitor Shelf
with Speakers
Z-release Handle, releases Top
Console for up and down
movement.
XY-release Handle, releases Top
Console for forward, backward
and sideward movement,
