9-22-4 Digital Video Disc Recorder (DVR)
9-22-5 Video Cassette Recorders (VCRs)
9-22-6 USB Flash Card (USB Drive)
Table 9-52 DVD Recorder used on Vivid 7 (Introduced BT’06)
ITEM PART NAME
PART
NUMBER DESCRIPTION QTY FRU
1 JVC BD-X201ME 066E9530 JVC DVD VIDEO RECORDER 1 Y
Table 9-53 VCRs used on Vivid 7
ITEM PART NAME
PART
NUMBER DESCRIPTION QTY FRU
1 VCR MITSUBISHI HS-MD3000E 066E9513
VCR MITSUBISHI HS-MD3000E SVHS RS-232C
PAL VERSION
Additional mounting bracket needed if used as replacement
for 066E9510 or 066E9511.
1
Y
2 VCR MITSUBISHI HS-MD3000U 066E9514
VCR MITSUBISHI HS-MD3000E SVHS RS-232C
NTSC VERSION
Additional mounting bracket needed if used as replacement
for 066E9510 or 066E9511.
Y
3 Analog VCR PAL 066E9510
SONY SVO9500MDP2
SUPER-VHS, PAL
Needs software V2.0 (BT’02) or higher
Y
4 Analog VCR NTSC 066E9511
SONY SVO9500MD
SUPER-VHS, NTSC
Needs software V2.0 (BT’02) or higher
Y
Table 9-54 USB Flash Card (USB Drive)
ITEM Part Name
Part
Number Description QTY FRU
1
USB Drive 256 MB USB 2.0
The following models have been
approved for use with
Vivid 7:.
- Kingston DataTraveler Elite 256 MB
- Sandisk Cruzer Micro 256 MB
- Twin MOS K24-256MB Mobile Disk III
- JMTek
066E0693
066E0692
066E0691
066E0690
USB FLASH CARD (USB Drive 256 MB USB 2.0)
1N
