3-9-16 Create a New Dataflow
3-9-16-1 Overview
It is possible to make new dataflows by combining the predefined settings. The table below describes
the legal combination of inputs and outputs in a dataflow.
3-9-16-2 Create a New Dataflow with Worklist, Database and DICOM Storage
(Introduced for software v4.0)
To create a new dataflow with Worklist, Database and DICOM Storage, do the following in exactly these
steps:
1.) Add the Worklist Input, highlight it, select properties, and name it (i.e.: DR PACS Worklist or just
Worklist).
Go to the IP Address field, scroll down and select <Modify>. This will allow you to edit or add IP
Addresses (New Destinations/devices). If the correct IP Address is already in the list, just select it.
2.) Add the Database Input/Output, highlight it, select properties, and name it (i.e.: Local Archive - Int
HD).
Go to the IP Address field and (if the Database is to be the Local Archive) verify that "My Computer"
is selected.
The IP Address should then be correct and the Database Name and Archive File Location entries
should auto-populate correctly.
Table 3-16 Allowed combinations of inputs and outputs in a dataflow
NOTICE
Failure to add destinations to the dataflow in the correct order may or will cause intermittent errors.
Output
Input
No
Output
Database
Remote
Database
DICOM
MOD
5.25
DICOM
MOD
3.5
DICOM
Storage
DICOM
Print
Database
+
DICOM
MOD
5.25/3.5
Database
+
DICOM
Storage
Remote
Database
+
DICOM
MOD
5.25/3.5
Remote
Database
+
DICOM
Storage
Database
XXX
Remote Database
X XX
DICOM Worklist
X
DICOM CD
X
DICOM MOD 5.25
X
DICOM MOD 3.5
X
Query/Retrieve
X
EchoPAC Mac
X
Worklist/database
X X
Worklist/rem database
X X
No input device
X X
