GE HEALTHCARE
DIRECTION FC091194, REVISION 11 VIVID 7 SERVICE MANUAL
5 - 52 Section 5-3 - a Front-End Processor (FEP)
5-3-19 Spectrum Doppler Processor Board, SDP (cont’d)
5-3-19-7 Location in the Unit
5-3-19-8 Input Signals
5-3-19-9 Bi-directional Signals
Figure 5-34 SPD Board - Location in Unit
Table 5-41 Input signals
INPUT DESCRIPTION CONNECTION FROM:
PipeLink Doppler Signals extracted RFT Board
Serial Trace Data Analog Traces Patient I/O via Internal I/O
Table 5-42 Bi-directional signals
INPUT DESCRIPTION CONNECTION FROM:
VME Bus Data communication BEP
SDP Board
Front of
Scanner
