DIRECTION FC091194, REVISION 11 VIVID 7 SERVICE MANUAL
5 - 118 Section 5-8 - External I/O
5-8-1 General Description, External I/O (cont’d)
The External I/O has the following external connectors available at the rear of the system:
• Sound out (Right and Left channels - Stereo)
•Trig Out
• Footswitch
• RS-232 Serial Port (Not Used)
• Remote Expose 1
• Remote Expose 2
• Modem (Not Used)
• Composite Video Out
• B/W Video Out
• Svideo Out
• SVGA Out
•USB
• Ethernet
5-8-2 Location in the Unit
At the rear of the scanner, above the power inlet and power breaker.
Figure 5-74 External I/O Connector Panel
