5-6-4 Output Signals from the Internal I/O (cont’d)
5-6-4-3 Interface Connectors – “Back-End Processor Side”
5-6-4-4 Interface Connectors – “Front-End Processor Side”
Table 5-77 Connectors – “Back-End Processor side”
Input Description Connection from
A1/J1 B&W printer, 15pins HD-sub, female. A1 > J1
A2/P4 VCR remote ctrl – RS232: 9pins D-sub, male.
A3/P5 Color printer - RS232: 9pins D-sub, male.
A4/J2 Top Console - Power & signals: 15pins D-sub, female.
A5/P4 Top Console - Signals: 15pins D-sub, male.
A6/J6 Audio out to VCR, left: Phono jack.
A7/J7 Audio out to VCR, right: Phono jack.
A8/J8 Audio in from VCR, left: Phono jack.
A9/J9 Audio in from VCR, right
A10/J10 SVHS out to VCR
A11/J11 SVHS in from VCR
B1/J12 USB to Top console
B2/J13 USB to external I/O
B3/J14 Ethernet
B4/J15 Audio I/O
B5/J16 PC2IO signals
B6/J17 PC2IO power
B7/P18 COM1
B8/P19 COM2
B9/P25 UPS remote control
J32 MBD – signals and power
Table 5-78 Connectors - “Front-End Processor side”
Input Description Connection from
A12/J21 Spare power, 15pins D-sub, female
A13/J20 Spare – power, 15pins D-sub, female
A14/J24 AC power ctrl, 9pins D-sub, female
A15/P23
Rotation adapter – signals, 15 pins
D-sub, male
A16/P22 Spare – signals, 25pins D-sub, female
P30 EIO – signals and power, 110pins male
