4-3-9-2 Preparations (cont’d)
Figure 4-32 Doppler Mode Controls
Gain *
Mode Dependant Keys
Horizontal Sweep *
Velocity Range
Baseline *
LVR
Invert *
LPRF (in PW mode only)
Color Maps *
Soft menu
Sample Vol. (PW)
Compress *
Reject *
Frequency
Frame Rate
Angle Corr. *
Power
CW
Freeze
PW
Zoom
Display zoom
HR zoom
Controls marked with * (asterisk) are also available in freeze and cine replay
