GE HEALTHCARE
DIRECTION FC091194, REVISION 11 VIVID 7 SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5 - 57
5-3-20 Image Port (IMP) Board (cont’d)
5-3-20-2 Location in the Unit
Figure 5-36 IMP Board - Location in Unit
IMP2 Board
Front of
Scanner
