Chapter 9 - Renewal Parts 9 - 39
FC200459 TX128-5 03
03
(requires
software
v4.2.0 or
later)
03 03 03
TRANSMITTER BOARD VERSION 5
2X TO BE USED IN UNITS WITH RT3D/4D
NOTE! Do not install one FC200459 and one
FC200375 in the same Vivid 7.
- MCD REV 07 DOC. ERROR FIX.
- MCD REV 06 Improved Manufacturing
process.
- MCD REV 05 Improved tolerances.
(Manufacturing).
- MCD REV 04 Removed unused components.
- MCD REV 03 is the first released version of
this card.
FC200375 TX128-4 01 03 03 03 03
TRANSMITTER BOARD VERSION 4
2X TO BE USED IN UNITS WITH RT3D/4D.
NOTE! Do not install one FC200459 and one
FC200375 in the same Vivid 7.
FC200239 XDBUS-3 01 01 01 01 01
TRANSDUCER BUS BOARD VERSION 3
2X USED
FC200364 XDBUS-4 N/A 01 01 01 01
TRANSDUCER BUS BOARD VERSION 4
2X USED
TO BE USED IN UNITS WITH RT3D/4D
FC200100
BF64 WITH
4 MLA
01 01 01 01 01
2X USED
FC200054 RFI 04 N/A N/A N/A N/A
INTRODUCED 2003.
FOR UNITS WITHOUT SUPPORT FOR 3D
OPTION.
OBSOLETE, PLEASE ORDER FC200507
FC200507 RFI 01 02 02 02 02
CARD WITH SUPPORT FOR 3D OPTION
FA200945 POWER, DC 02 02 02 02 02
Issues on some systems when using 3V
PROBE in CW. mode.
OBSOLETE, PLEASE ORDER FD200041
FD200041 POWER, DC 01 01 01 01 01
Increased +6VDC output current for use with
3V PROBE in CW mode.
FB200574
POWER, TX
(TXPS)
02 N/A N/A N/A N/A
BT’03:
USED IN ALL SYSTEMS
BT’04 and later:DON’T USE.
FC200386
POWER, TX
(TXPS)
N/A03030303
BT’04 and later:
TO BE USED IN ALL SYSTEMS.
Table 9-30 Required Revisions for Cards and Modules, FEP2 (cont’d) sheet 2 of 2
2nd VERSION OF FRONT-END CARD CAGE (FEP2)
PART
NUMBER
NAME
BT’03
(SW. v3.2.x/
v3.4.x/
v3.6.x)
BT’04
(SW. v4.x)
BT’05
(SW. v5.x)
BT’06
(SW. v6.x)
BT’08
(SW. v7.x)
COMMENTS
MCD MCD MCD MCD MCD
