9 - 120 Section 9-33 - Packing Parts for Reshipment - Vivid 7 with LCD
Section 9-33
Packing Parts for Reshipment - Vivid 7 with LCD
Figure 9-38 Packing Material (current versions) - LCD
Table 9-99 Packing Material for Reshipment of Vivid 7 with LCD
ITEM DESCRIPTION PART NUMBER COMMENTS
1 Rear Stop Bumper -
NOTE 1:
The Shelf Reinforcement (Item #4) may look slightly different, de-
pending on Vivid 7/Vivid 7 PRO model needs.
NOTE 2:
Transportation Box used for China is slightly different.
Re-shipping Unit:
Re-use the original Transportation Box and other packing materials
used for shipment
2 Front Stop Bumper -
3 Front Panel Reinforcement -
4 Shelf Reinforcement -
5 Wedge -
6 Monitor Reinforcement -
7 Plate -
8 Pink plate -
9 Transportation Box -
Plastic Foil - To wrap around the unit
1
2
3
4
5
6
7
9
