GE HEALTHCARE
DIRECTION FC091194, REVISION 11 VIVID 7 SERVICE MANUAL
Chapter 1 - Introduction 1 - 49
1-5-17 Labels on Internal I/O (Inside Scanner) (cont’d)
Figure 1-4 Label on Internal I/O on units with BEP2
B1 USB#1 (top console conection)
B2 USB#2 (external i/o connection)
B3 10/100 Base-TX Ethernet
B4 Audio in to BEP, Audio out from BEP, Microphone in to BEP
B5 PC2IO board signals
B6 PC2IO board signals and power
B7 COM (external i/o connection) NOT USED
B8 COM (modem - setup as COM2)
B9 BEP Power Supply control (UPS)
A1 BW printer video, printer remote control
A2 VCR remote control (RS232)
A3 Spare RS232
A4 Signals & power to/from top console
A5 Signals to/from top console
A6 Audio left out to VCR
A7 Audio right out to VCR
A8 Audio left reply from VCR
A9 Audio right reply from VCR
A10 SVideo out to VCR
A11 SVideo in from VCR
81
15 9
F
69
1
5
M
69
1
5
M
1
13
1425
F
5
1
9
6
F
69
1
5
M
A3
69
1
5
M
Connectors to/from Back End
Connector to motherboard
P31
P32
-5V
-15V
+3.3V
+5V
+6V
+10V
+15V
+5V
+12V
From
Back
End
i
nt
e
r
na
l
I
O
m
o
d
ul
e
s
e
e
n
f
r
o
m
Bac
k
En
d
P
r
oce
s
s
o
r(
BEP
)
s
i
de
A2
51
15 11
610
F
A1
A4
18
915
M
A5
A6
A7
A10
A11
A8
A9
B1 B2
B3
B4
50
125
26
F
B5
B6
B7
B8
69
1
5
M
B9
To Next Page
