Table 49: Optical Interface Support for Fast Ethernet and Gigabit Ethernet SFP Transceivers

in EX9200 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-GE10KT13R14Model number1000BASE-BX-U

1000 MbpsRate

LCConnector type

SingleFiber count

1310 nmTransmitter

wavelength

1490 nmReceiver

wavelength

–9 dBmMinimum launch

power

–3 dBmMaximum launch

power

–30 dBmMinimum receiver

sensitivity

–3 dBmMaximum input

power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

10 km (6.2 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 12.3R2 or laterSoftware required
