Table 51: Optical Interface Support for SFP+ Transceivers in EX9200 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-10GE-LRModel number10GBASE-LR

10 GbpsRate

LCConnector type

DualFiber count

1310 nmTransmitter wavelength

–8.2 dBmMinimum launch power

0.5 dBmMaximum launch power

–18 dBmMinimum receiver sensitivity

0.5 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

10 km (6.2 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 12.3R2 or laterSoftware required
