Keysight x-series User Reference Guide

12 Disturbance Analyzer Measurement
SPAN X Scale
Full Scale
Shows the data of all traces on the screen by setting the Ref Value to 0s and Scale/Div to Max value. The
maximum value of Scale/Div is dependent on the Duration value.
Key Path
SPAN X Scale
Remote Command
:DISPlay:DANalyzer:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:FULL
Example DISP:DAN:VIEW:WIND:TRAC:X:FULL
Initial S/W Revision A.14.00
1120 EMI Receiver Mode Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
