8 Frequency Scan Measurement
Meas Setup
When the limits are frequency limits but the trace is a zero-span trace, the limit trace is drawn at the limit
amplitude of the center frequency. When the limits are time limits but the trace is a frequency domain
trace, the limit trace is drawn according to the current time axis, with the left of the screen being 0 and the
right being equal to sweep time.
Key Path
Meas Setup, Limits
Remote Command
:CALCulate:FSCan:LLINe[1]|2|...|6:DISPlay ON|OFF|1|0
:CALCulate:FSCan:LLINe[1]|2|...|6:DISPlay?
Example CALC:FSC:LLIN2:DISP ON
CALC:FSC:LLIN2:DISP?
Couplings Limit display ON selects the limit. Testing is done on all displayed limits if Test Limits (All Limits) is
ON. Entering the limit menu from the GUI turns on the selected limit.
Preset OFF
State Saved Saved in instrument state.
Range On|Off
Backwards
Compatibility SCPI
:CALCulate[1]|2:LIMit[1]|2|...|6:STATe
Backwards Compatibility
SCPI Notes
This command above is included for ESU compatibility. The suffix [1]|2 is irrelevant to the
measurement, they are added solely for remote language compatibility.
Initial S/W Revision A.07.00
Properties
Accesses a menu that lets you set the properties of the selected limit.
Key Path
Meas Setup, Limits
Initial S/W Revision A.07.00
Select Limit
Specifies the selected limit. The term “selected limit” is used throughout this document to specify which
limit will be affected by the functions.
Key Path
Meas Setup, Limits
Notes Front panel only. The selected limit is remembered even when not in the Limit Menu.
Preset Limit 1, not affected by Mode Preset, preset by Restore Mode Defaults.
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Test Trace
Selects the trace that you want the limit to test. A limit is applied to one and only one trace.
484 EMI Receiver Mode Reference
