Keysight x-series User Reference Guide

10 Monitor Spectrum Measurement
Save
• Frequency Interpolation: Logarithmic, Linear
Amplitude Correction
These keys let you choose which Correction to save. Once selected, the key returns back to the Export
Data menu and the selected Correction number is annotated on the key.
The next step in the Save process is to select the Save As key in the Export Data menu.
Key Path
Save, Data, Amplitude Correction
Preset Not part of a Preset, but is reset to Correction 1 by Restore Input/Output Defaults. Survives a
shutdown.
Readback 1
Initial S/W Revision A.02.00
Trace
Pressing this key selects Traces as the data type to be exported. Pressing this key when it is already
selected brings up the Trace Menu, which allows you to select which Trace to save.
The trace file contains “meta” data which describes the current setting of the analyzer, but it is not eh full
state of the analyzer. The trace file content is detailed in:
"Frequency Scan Trace File Content" on page 847
"Strip Chart Trace File Content" on page 848
"Monitor Spectrum Trace File Content" on page 849
Key Path
Save, Data
Remote Command
:MMEMory:STORe:TRACe:DATA TRACE1 | TRACE2 | TRACE3 | ALL,<filename>
Example :MMEM:STOR:TRAC:DATA TRACE2, "myTrace2.csv" exports the 2nd trace to the file myTrace2.csv
in the current path. The default path is My Documents\EMI\data\xxx\Traces where xxx is the
measurement name.
Notes If the save is initiated via SCPI, and the file already exists, the file will be overwritten.
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade.
Both single and double quotes are supported for any filename parameter over SCPI.
Dependencies Traces cannot be recalled from a trace file that was saved with ALL traces selected.
Readback 1|2|3|All
Status Bits/OPC
dependencies
Sequential - waits for previous measurement to complete
Initial S/W Revision Prior to A.02.00
Frequency Scan Trace File Content
The following file example shows the Trace file content in Excel for one trace.
EMI Receiver Mode Reference 847

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
