10 Monitor Spectrum Measurement
Marker
2 – Trace 2
3 – Trace 3
4 – Freq Scan Trace 1
5 – Freq Scan Trace 2
6 – Freq Scan Trace 3
Couplings The state of Marker Trace is not affected by the Auto Couple key.
If a Marker Trace is chosen manually, Auto Init goes to Off for that marker.
Sending the remote command causes the addressed marker to become selected.
Preset 1
State Saved The Marker Trace and state of Auto Init for each marker is saved in instrument state.
Readback line TraceN where N is the trace number to which the marker is currently assigned.
Initial S/W Revision A.13.00
Couple Marker
When this function is invoked, moving any marker causes an “equal X Axis movement” of every other
marker which is active. By “equal X Axis movement” we mean that the difference between each marker’s X
Axis value (in the fundamental x-axis units of the trace that marker is on) is preserved, as is the X Axis value
of the marker being moved (in the same fundamental X-axis units).
Key Path
Marker
Remote Command
:CALCulate:MONitor:MARKer:COUPle[:STATe] ON|OFF|1|0
:CALCulate:MONitor:MARKer:COUPle[:STATe]?
Example CALC:MON:MARK:COUP ON
CALC:MON:MARK:COUP?
Preset OFF
State Saved Saved in instrument state
Initial S/W Revision A.13.00
All Markers Off
Turns all markers Off.
Key Path
Marker
Remote Command
:CALCulate:MONitor:MARKer:AOFF
Example :CALC:MON:MARK:AOFF
Couplings sets the selected marker to 1.
Initial S/W Revision A.13.00
EMI Receiver Mode Reference 761
