10 Monitor Spectrum Measurement
AMPTD Y Scale
dBpW
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBpW.
Key Path
AMPTD Y Scale, Y Axis Unit
Example UNIT:POW DBPW
Dependencies Grayed out if an Amplitude Correction with an Antenna Unit is ON.
Readback dBµA
Initial S/W Revision A.11.00
Antenna Unit
When a Correction is turned on that uses an Antenna Unit, the Y Axis Unit changes to that Antenna Unit. All
of the keys in the Y-Axis Unit menu are then greyed out, except the Antenna Unit key. The unit being used is
shown on this key and is shown as selected in the submenu.
Key Path
AMPTD Y Scale, Y Axis Unit
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback line Currently selected unit
Initial S/W Revision A.11.00
dBµV/m
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBµV/m. This is an antenna unit, and
this key is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the
other Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Y Axis Unit, Antenna Unit
Example UNIT:POW DBUVM
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBµV/m
Initial S/W Revision A.02.00
dBµA/m
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBµA/m. This is an antenna unit, and
this key is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the
other Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Y Axis Unit, Antenna Unit
738 EMI Receiver Mode Reference
