Keysight x-series User Reference Guide

10 Monitor Spectrum Measurement
Save
Trace
EMI:FSCAN
A.07.00 N9020A
526 EA3 B25 P26 PFR 1
Preselector On
Scan Type Smooth
Number of scans 1
Y Axis Unit dBuV
Ref Level Offset 0 dB
Coupling AC
Input Z Correction 50 ohm
Data
Trace 1
Detector Peak
30000000 –91.67179747
30060002.47 –91.73843172
30120004.95 –88.07746798
30180007.42 –90.05428387
30240009.9 –86.55925246
30300012.37 –87.6724363
30360014.85 –93.18478677
30420017.32 –95.06361113
30480019.79 –91.02766645
30540022.27 –90.66836416
30600024.74 –87.10931161
Strip Chart Trace File Content
The following file example shows the Trace file content in Excel.
AllTrace
EMI:SCHart
A.07.00_R0009 N9020A
526 EA3 B25 P26 PFR 1
848 EMI Receiver Mode Reference
