8 Frequency Scan Measurement
Meas Setup
:SENSe1|SENSe2|[:SENSe]:FMEasurement:LISN:FILTer:HPAS[:STATe]?
Example :FME:LISN:FILT:HPAS ON
Notes This key is only available when ENV216 V-network is selected.
Dependencies This key is grayed out when V-network other than ENV216 is selected. If the grayed out key is
pressed, an advisory message is generated. If the equivalent SCPI command is sent, this same
message is generated as part of a “–221, Setting Conflict; Function not available with current LISN
Type” warning.
Couplings This key is coupled to 150kHz Highpass of LISN Control in Mode Setup panel, and vice versa.
Preset OFF
State Saved Saved in instrument state
Range ON|OFF
Initial S/W Revision A.13.50
Protective Earth
Selects the ground settings of the V-network.
Key Path
Meas Setup, LISN Control, Settings
Remote Command
:SENSe1|SENSe2|[:SENSe]:FMEasurement:LISN:PEARth GROunded | FLOating,
[GROunded | FLOating]
:SENSe1|SENSe2|[:SENSe]:FMEasurement:LISN:PEARth?
Example :FME:LISN:PEAR GRO,FLO
Notes This key is only available when ESH2Z5 V-network is selected.
Dependencies This key is grayed out V-networks other than ESH2Z5 is selected. If the equivalent SCPI command is
sent, this same message is generated as part of a “–221, Setting Conflict; Function not available with
current LISN Type” warning.
Couplings If users try to turn off both protective earth from front panel, an advisory message is generated as “At
least one Protective Earth must be turned on”.
Preset Grounded
State Saved Saved in instrument state
Range GRO|FLO
Initial S/W Revision A.13.50
Meas Preset
Returns the measurement local variables in the current measurement to their preset values.
Remote Command
:CONFigure:FSCan
Example CONF:FSC
Initial S/W Revision A.07.00
506 EMI Receiver Mode Reference
