Keysight x-series User Reference Guide

3 Programming the Analyzer
STATus Subsystem
Mode All
Remote Command
:STATus:OPERation:NTRansition <integer>
:STATus:OPERation:NTRansition?
Example STAT:OPER:NTR 1 Align Now operation complete will be reported to the Status Byte Register.
Preset 0
Min 0
Max 32767
Status Bits/OPC
dependencies
Sequential command
Initial S/W Revision Prior to A.02.00
Operation Positive Transition
This command determines which bits in the Operation Condition register will set the corresponding bit in
the Operation Event register when the condition register bit has a positive transition (0 to 1). The variable
<integer> is the sum of the decimal values of the bits that you want to enable.
Mode All
Remote Command
:STATus:OPERation:PTRansition <integer>
:STATus:OPERation:PTRansition?
Example STAT:OPER:PTR 1 Align Now operation beginning will be reported to the Status Byte Register.
Preset 32767
Min 0
Max 32767
Status Bits/OPC
dependencies
Sequential command
Initial S/W Revision Prior to A.02.00
Preset the Status Byte
Sets bits in most of the enable and transition registers to their default state. It presets all the Transition
Filters, Enable Registers, and the Error/Event Queue Enable. It has no effect on Event Registers,
Error/Event QUEue, IEEE 488.2 ESE, and SRE Registers as described in IEEE Standard 488.2–1992, IEEE
Standard Codes, Formats, Protocols, and Common Commands for Use with ANSI/IEEE Std 488.1–1987.
NewYork, NY, 1992.
Remote Command
:STATus:PRESet
Example STAT:PRES
Initial S/W Revision Prior to A.02.00
EMI Receiver Mode Reference 113
