8 Frequency Scan Measurement
View/ Display
Default Unit Depends on the current selected Y axis unit
Initial S/W Revision Prior to A.02.00
System Display Settings
These settings are "Mode Global" – they affect all modes and measurements and are reset only by Restore
Misc Defaults or Restore System Defaults under System.
Key Path
View/Display, Display
Initial S/W Revision Prior to A.02.00
Annotation Local Settings
This is a Mode Global override of the meas local annotation settings. When it is All Off, it forces
ScreenAnnotation, Meas Bar, Trace, and Active Function Values settings to be OFF for all measurements
in all modes. This provides the security based "annotation off" function of previous analyzers; hence it uses
the legacy SCPI command.
When it is All Off, the Screen, Meas Bar, Trace, and Active Function Values keys under the Display,
Annotation menu are grayed out and forced to Off. When Local Settings is selected, you are able to set the
local annotation settings on a measurement by measurement basis.
Key Path
View/Display, Display, System Display Settings
Remote Command
:DISPlay:WINDow[1]:ANNotation[:ALL] OFF|ON|0|1
:DISPlay:WINDow[1]:ANNotation[:ALL]?
Example :DISP:WIND:ANN OFF
Preset On (Set by Restore Misc Defaults)
State Saved Not saved in instrument state.
Backwards Compatibility
Notes
The WINDow parameter and optional subopcode is included for backwards compatibility but ignored
– all windows are equally affected.
Initial S/W Revision Prior to A.02.00
Themes
Accesses a menu of functions that enable you to choose the theme to be used when saving the screen
image.
The Themes option is the same as the Themes option under the Display and Page Setup dialogs. It allows
you to choose between themes to be used when saving the screen image.
Key Path
Save, Screen Image
Remote Command
:MMEMory:STORe:SCReen:THEMe TDColor | TDMonochrome | FCOLor |
FMONochrome
EMI Receiver Mode Reference 601
