Keysight x-series User Reference Guide

11 APD Measurement
Meas Setup
Frequency of Disturbance Level Limit (Remote Command Only)
Defines a list of frequency values for a given disturbance level limit line. Up to 2000 points may be defined
for each limit using the following parameters.
Remote Command
:CALCulate:APD:LLINe[1]:DLEVel:CONTrol[:DATA] <x>, <x>, …
:CALCulate:APD:LLINe[1]:DLEVel:CONTrol[:DATA]?
Example CALC:APD:LLIN:DLEV:CONT 1GHz, 2GHz, 2GHz, 3GHz Describes the X values of a stair-stepped
limit line.
CALC:APD:LLIN:DLEV:CONT?
Preset Unaffected by Preset
State Saved Saved in instrument state.
Initial S/W Revision A.13.00
Remote Command
:CALCulate:APD:LLINe[1]:DLEVel:CONTrol:POINts?
Example CALC:APD:LLIN:DLEV:CONT:POIN? Returns the number of points in the limit line.
Preset 1
State Saved Saved in instrument state.
Initial S/W Revision A.13.00
Frequency of Probability Limit (Remote Command Only)
Defines a list of frequency values for a given probability limit line. Up to 2000 points may be defined for each
limit using the following parameters.
Remote Command
:CALCulate:APD:LLINe[1]:PROBability:CONTrol[:DATA] <x>, <x>, …
:CALCulate:APD:LLINe[1]:PROBability:CONTrol[:DATA]?
Example CALC:APD:LLIN:PROB:CONT 1GHz, 2GHz, 2GHz, 3GHz Describes the X values of a stair-stepped
limit line.
CALC:APD:LLIN:PROB:CONT?
Preset Unaffected by Preset
State Saved Saved in instrument state.
Initial S/W Revision A.13.00
Remote Command
:CALCulate:APD:LLINe[1]:PROBability:CONTrol:POINts?
Example CALC:APD:LLIN:PROB:CONT:POIN? Returns the number of points in the limit line.
Preset 1
State Saved Saved in instrument state.
Initial S/W Revision A.13.00
EMI Receiver Mode Reference 951
