8 Frequency Scan Measurement
Recall
Couplings When a correction file is loaded from mass storage, it is automatically turned on (Correction ON) and
ApplyCorrections is set to On. This allows you to see its effect, thus confirming the load.
Readback selected Correction
Backwards
Compatibility SCPI
:MMEMory:LOAD:CORRection ANTenna | CABLe | OTHer | USER, <filename>
For backwards compatibility, ANTenna maps to 1, CABle maps to 2, OTHer maps to 3 and USER
maps to 4
Initial S/W Revision A.02.00
Default Directory
Specifies the default directory used for loading of Amplitude Correction. If user is selected, the default
recall directory is the default (My Documents\amplitudeCorrections) or the last directory you saved the
amplitude correction data to. Otherwise, the default recall directory is My Documents\EMC Limits and
Ampcor\Ampcor, which contains a set of preloaded amplitude correction files in the directory called
Ampcor.
Key Path
Recall, Export Data, Amplitude Correction
Remote Command
:MMEMory:LOAD:CORRection:DDIRectory USER|PRELoaded
Example :MMEM:LOAD:CORR:DDIR USER Select user
:MMEM:LOAD:CORR:DDIR?
Notes USER = User
PRELoaded = Preloaded
Preset PRELoaded
State Saved Saved in instrument state.
Range User| Preloaded
Readback “User”| “Preloaded”
Initial S/W Revision A.13.00
Trace
This key selects Trace as the data type to be imported. When pressed a second time, it brings up the Trace
Menu, which lets you select the Trace into which the data will be imported.
The trace file contains “meta” data which describes the state of the analyzer when the trace was exported
(see ). If the meta data in the file does not match the current SA state, the “invalid data indicator” (*) is
displayed.
Key Path
Recall, Data
Remote Command
:MMEMory:LOAD:TRACe:DATA TRACE1|TRACE2|TRACE3,<filename>
Example :MMEM:LOAD:TRAC DATA TRACE2, "myTrace2.csv" imports the 2nd trace from the file
530 EMI Receiver Mode Reference
