Keysight x-series User Reference Guide

8 Frequency Scan Measurement
Trace/ Detector
Key Path
Trace/Detector
Example TRAC:FSC:TYPE AVER
Dependencies This key is grayed out when a scan sequence is running except during single range scanning. If the
grayed out key is pressed, an advisory message is generated. If the equivalent remote command is
sent, this same message is generated as part of a “–221, Settings conflict” warning.
Couplings Affected by # of Scans (Avg Number).
Whenever you press Average or send the equivalent remote command,
Update is set to On and Display is set to On.
Preset After a Preset, any trace that is in Trace Average is cleared (all trace points set to mintracevalue).
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Max Hold
In Max Hold type the analyzer maintains and displays a max hold trace, which represents the maximum
data value on a point-by-point basis of the new trace data and previous trace data.
Key Path
Trace/Detector
Example TRAC:FSC:TYPE MAX
Dependencies This key is grayed out when a scan sequence is running except during single range scanning. If the
grayed out key is pressed, an advisory message is generated. If the equivalent remote command is
sent, this same message is generated as part of a “–221, Settings conflict” warning.
Couplings Affected by # of Scans (Avg Number).
Whenever you press Max Hold or send the equivalent remote command, Update is set to On and
Display is set to On.
Preset After a Preset, any trace that is in Max Hold is cleared (all trace points set to
mintracevalue).
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Min Hold
In Min Hold type the analyzer maintains and displays a min hold trace, which represents the minimum data
value on a point-point basis of the new trace data and previous trace data.
Key Path
Trace/Detector
Example TRAC:FSC:TYPE MIN
Dependencies This key is grayed out when a scan sequence is running except during single range scanning. If the
grayed out key is pressed, an advisory message is generated. If the equivalent remote command is
sent, this same message is generated as part of a “–221, Settings conflict” warning.
EMI Receiver Mode Reference 579
