5 Mode Functions
Mode
• Standards specific modulation analysis including:
−Cellular: GSM/EDGE, cdma2000, W-CDMA, TD-SCDMA, LTE(FDD/TDD),
−LTE-Advanced and more
−Wireless networking: 802.11a/b/g, 802.11n, 802.ac, 802.16 WiMAX (fixed/mobile), WiSUN (MR-FSK
PHY)
−RFID
−Digital satellite video and other satellite signals, radar, LMDS
−Up to 400K bin FFT, for the highest resolution spectrum analysis
−A full suite of time domain analysis tools, including signal capture and playback, time gating, and
CCDF measurements
−20 simultaneous trace displays and the industry's most complete set of marker functions
−Easy-to-use Microsoft ® Windows ® graphical user interface
For more information see the Agilent 89600 Series VSA web site at www.agilent.com/find/89600vsa
To learn more about how to use the 89600 VSA running in the X-Series, after the 89600 VSA software is
running, open the 89600 VSA Help and open the "About Agilent X-Series Signal Analyzer with 89600 VSA
Software" help topic.
Key Path
Mode
Example INST:SEL VSA89601
INST:NSEL 101
Initial S/W Revision Prior to A.02.00
Analog Demod
Selects the Analog Demod mode for making measurements of AM, FM and phase modulated signals.
If you are using the Help feature, this mode must be currently active to access its detailed information. If it
is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Key Path
Mode
Example INST:SEL ADEMOD
INST:NSEL 234
Initial S/W Revision Prior to A.02.00
Bluetooth
Selects the Bluetooth mode for Bluetooth specific measurements. There are several measurements
available in this mode.
234 EMI Receiver Mode Reference
