Keysight x-series User Reference Guide

8 Frequency Scan Measurement
Marker To
Mkr à Meters (Move Meters to Marker Freq)
Replaces Frequency (Meters) with the frequency identified by the selected marker.
Key Path
Marker To
Remote Command
:CALCulate:FSCan:MARKer[1]|2|...|12:TO:METer
Example CALC:FSC:MARK2:TO:MET
Couplings
If no marker is ON when this operation is performed, the default marker will be turned on.
Initial S/W Revision A.07.00
Metersà Mkr (Move Marker to Meters Freq)
Replaces the frequency of the selected marker with Frequency (Meters). If the Meters frequency is out of
the current span, an error is generated and the marker is not moved.
Key Path
Marker To
Remote Command
:CALCulate:FSCan:MARKer[1]|2|...|12[:SET]:METer
Example
CALC:FSC:MARK2:MET
Couplings
If no marker is ON when this operation is performed, the default marker will be turned on.
Initial S/W Revision A.07.00
Meters à Signal (Replace)
Replaces the frequency of the selected signal with Frequency (Meters). Amplitude values and the Delta To
Limit values will be shown as “---“ to indicate an undefined value.
Key Path
Marker To
Remote Command
:CALCulate:FSCan:SLISt:REPLace:METer <integer>
Example
CALC:FSC:SLIS:REPL:MET 20 Replace Signal #20 with signal obtained at the meters.
Notes If the signal list contains no data, an error is generated and this function cannot be performed.
If the selected signal is not in the list, an error is generated and this function cannot be performed.
Initial S/W Revision A.07.00
Meters à List (Append)
Appends the signal obtained at meters into the signal list. Amplitude values and the Delta To Limit values
will be shown as “---“ to indicate an undefined value.
Key Path
Marker To
EMI Receiver Mode Reference 425
