8 Frequency Scan Measurement

Save

29749009.9 10.21771213

29750009.9 9.474250519

29751009.9 8.374183381

29752009.9 6.909049714

29753009.9 4.86714145

29754009.9 2.253837311

29755009.9 –0.937874114

29756009.9 –4.154472625

Limit

Pressing this key selects Limit Lines as the data type to be exported. Pressing the key a second time brings

up the Limit Menu that allows you to select which Limit Line to save.

See "Limits File Contents" on page 552.

See ".csv file format" on page 553

See ".lim file format" on page 554

Key Path

Save, Data

Remote Command

LLINE6,<filename>

Example :MMEM:STOR:LIM LLINE2, "myLimitLine2.csv" saves the 2nd Limit Line to the file myLimitLine2.csv

in the current path. The default path is My Documents\EMI\data\xxx\limits where xxx is the

measurement name.

Notes If the save is initiated via SCPI, and the file already exists, the file will be overwritten.

Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an

instrument software upgrade.

Both single and double quotes are supported for any filename parameter over SCPI.

Dependencies This key will only appear if you have the proper option installed in your instrument.

Preset 1; not part of Preset, but is reset by Restore Mode Defaults and survives power cycles

State Saved The selected Limit number is saved in instrument state.

Readback 1|2|3|4|5|6

Status Bits/OPC

dependencies

Sequential - waits for previous measurement to complete

Initial S/W Revision A.02.00

Limits File Contents

Limits may be exported into a data file with a .csv extension. They may be imported from that data file; they

may also be imported from a legacy limit file with a .lim extension. The .lim files meet the specification for
