Keysight x-series User Reference Guide

9 Strip Chart Measurement
Marker
Select Marker
Display a menu with 12 markers available for selection for the current measurement.
Key Path
Marker
Notes Front panel only. The selected marker is remembered even when not in the Marker menu and is used
Preset Marker 1
State Saved The number of the selected marker is saved in instrument state.
Initial S/W Revision A.07.00
Relative To
Select the reference marker for a marker in Delta mode.
Key Path
Marker, Properties
Remote Command
:CALCulate:SCHart:MARKer[1]|2|...12:REFerence <integer>
:CALCulate:SCHart:MARKer[1]|2|...12:REFerence?
Example CALC:SCH:MARK5:REF 1
CALC:SCH:MARK5:REF?
Notes A marker cannot be relative to itself so that choice is grayed out, and if sent from SCPI, generates
error –221: “Settings conflict; marker cannot be relative to itself.”
When queried, a single value will be returned - the specified marker number’s relative marker.
Preset 2
State Saved Saved in instrument state
Min 1
Max 12
Initial S/W Revision A.07.00
Marker Trace
Assign the specified marker to the designated trace.
Key Path
Marker, Properties
Remote Command
:CALCulate:SCHart:MARKer[1]|2|...12:TRACe 1|2|3
:CALCulate:SCHart:MARKer[1]|2|...12:TRACe?
Example CALC:SCH:MARK1:TRAC 2 places marker 1 on trace 2.
EMI Receiver Mode Reference 637
