Keysight x-series User Reference Guide

9 Strip Chart Measurement
View/Display
View/Display
Opens the Display and View menus.
Key Path
Front-panel key
Initial S/W Revision A.07.00
Display
The Display menu is common to most measurements, and is used for configuring items on the display.
Some Display menu settings apply to all the measurements in a mode, and some only to the current
measurement. Those under the System Display Settings key apply to all measurements in all modes.
Key Path
Display
Key Path
View/Display
Initial S/W Revision Prior to A.02.00
Annotation
Turns on and off various parts of the display annotation. The annotation is divided up into four categories:
1. Meas Bar: This is the measurement bar at the top of the screen. It does not include the settings panel or
the Active Function. Turning off the Meas Bar turns off the settings panel and the Active Function. When
the Meas Bar is off, the graticule area expands to fill the area formerly occupied by the Meas Bar.
2. Screen Annotation: this is the annotation and annunciation around the graticule, including any
annotation on lines (such as the display line, the threshold line, etc.) This does NOT include the marker
number or the NdB result. When off, the graticule expands to fill the entire graticule area.
3. Trace annotation: these are the labels on the traces, showing their detector (or their math mode).
4. Active Function annotation: this is the active function display in the meas bar, and all of the active
function values displayed on softkeys.
See the figure below. Each type of annotation can be turned on and off individually.
EMI Receiver Mode Reference 715
