8 Frequency Scan Measurement
Sweep/ Control
Sweep/ Control
Displays the menu of keys that enable you to control the sweep parameters.
Key Path
Front-panel key
Notes Front panel only.
Initial S/W Revision A.07.00
Continuous/ Single Scan
This key determines whether the scan is continuous or single. The scan will not start until you manually
initiate the scanning through the Start or Clear List and Start key.
Key Path
Sweep/Control
Remote Command
INITiate2:CONTinuous ON|OFF|1|0
INITiate2:CONTinuous?
Example INIT2:CONT ON
Dependencies When a Scan Only scan is running, changing this parameter to single will finish the current scan and
stop. When the scan sequence = Scan Only, and no scan is running, changing this parameter will
start a scan.
When a scan sequence other than Scan Only is running, changing this parameter will have no impact
on the measurement. The scan will always be single in this case
Couplings For single scanning:
When the specified # of scans is complete, the scan will stop. Any parameter change before the
scans complete will restart the scans (Scan number recount from zero). Any parameter change after
the scans complete will NOT restart the scans. You need to manually start the scan.
For continues scanning:
When the specified # of scans completes, it continues to scan with exponential averaging/ holds. Any
parameter change after the scans complete will NOT restart the scans. You need to manually start
the scan.
Preset ON
State Saved Saved in instrument state.
Range ON|OFF
Initial S/W Revision A.07.00
Pause / Resume
Allows you to pause the scan, search or final measurement. When paused, the label on the key changes to
Resume. Pressing the Resume key resumes the scan at the point it was at when paused. A scan can only
be paused between ranges.
Key Path
Sweep/ Control
EMI Receiver Mode Reference 573
