6 System Functions
System
SICL Server
Turns the SICL server capability On or Off, enabling you to limit SCPI access over LAN through the SICL
server. (SICL IEEE 488.2 protocol.)
Parameter Description Setting
Maximum Connections The maximum number of connections that can be accessed
simultaneously
5
Instrument Name The name (same as the remote SICL address) of your analyzer inst0
Instrument Logical Unit The unique integer assigned to your analyzer when using SICL
LAN
8
Emulated GPIB Name The name (same as the remote SICL address) of the device used
when communicating with your analyzer
gpib7
Emulated GPIB Logical Unit The unique integer assigned to your device when it is being
controlled using SICL LAN
8
Emulated GPIB Address The emulated GPIB address assigned to your transmitter tester
when it is a SICL server (the same as your GPIB address)
18
Key Path
System, I/O Config, SCPI LAN
Mode All
Remote Command
:SYSTem:COMMunicate:LAN:SCPI:SICL:ENABle OFF|ON|0|1
:SYSTem:COMMunicate:LAN:SCPI:SICL:ENABle?
Example :SYST:COMM:LAN:SCPI:SICL:ENAB OFF
Preset This is unaffected by Preset, but is set to ON with a “Restore System Defaults->Misc”
State Saved No
Range On | Off
Initial S/W Revision Prior to A.02.00
HiSLIP Server
Turns the HiSLIP server capability On or Off, enabling you to limit SCPI access over LAN through the HiSLIP
server.
HiSLIP stands for High Speed LAN Instrument Protocol and is part of the IVI–6.1 specification.
Here is an example of a VISA connection string used to connect to the HiSLIP Server on an X-Series
Spectrum Analyzer:
TCPIP0::a-n9030a–93016::hislip0::INSTR
In the example above, hislip0 is the HiSLIP device name that VISA users must include in their HiSLIP VISA
Address strings. Your HiSLIP device name may be different depending on your VISA settings.
Key Path
System, I/O Config, SCPI LAN
EMI Receiver Mode Reference 335
