12 Disturbance Analyzer Measurement
Meas Setup
Zoom
Zoom will show trace data to the entire graticule display by magnifying 10% of the current trace data on
the selected disturbance.
Key Path
Meas Setup, Disturbance List
Remote Command
:CALCulate:DANalyzer:DLISt:ZOOM <integer>
Example CALC:DAN:DLIS:ZOOM 3
Notes
If the display range is out of the defined Min or Max of x-axis value of traces, the zoom function will
be limited to Min or Max of x-axis value of traces.
Dependencies This key is grayed out if the new traces range is out of limit of the Min value of x-scale/div after
magnifying the traces.
If the grayed out key is pressed, an advisory message is generated. If the equivalent SCPI command is
sent, this same message is generated as part of a “–200, Execution error” warning.
Couplings The Ref Value and Scale/Div will be changed to accommodate the new span when disturbance zoom
executes.
Initial S/W Revision A.14.00
Zoom Out
Restores back to the previous disturbance zoom range completely.
Key Path
Meas Setup, Disturbance List
Remote Command
:CALCulate:DANalyzer:DLISt:ZOOM:OUT
Example CALC:DAN:DLIS:ZOOM:OUT
Initial S/W Revision A.14.00
Setup Table
Setup Table is used to enter the measurement settings.
Key Path
Meas Setup
Initial S/W Revision A.12.00
Frequency
Sets the frequency of the measurement. This is for the current measurement and not the global
measurement frequency of all the other measurements
1064 EMI Receiver Mode Reference
