10 Monitor Spectrum Measurement
FREQ Channel
Key Path
FREQ Channel
Remote Command
[:SENSe]:FREQuency:CENTer:STEP[:INCRement] <freq>
[:SENSe]:FREQuency:CENTer:STEP[:INCRement]?
[:SENSe]:FREQuency:CENTer:STEP:AUTO OFF|ON|0|1
[:SENSe]:FREQuency:CENTer:STEP:AUTO?
Example FREQ:CENT:STEP:AUTO ON
FREQ:CENT:STEP 500 MHz
FREQ:CENT UP increases the current center frequency value by 500 MHz
FREQ:CENT:STEP?
FREQ:CENT:STEP:AUTO?
Notes Preset and Max values are dependent on Hardware Options (503, 508, 513, 526)
Preset Auto
ON
State Saved Saved in instrument state
Min – ( the maximum frequency of the instrument). (that is, a 27 GHz max freq instrument has a CF step
range of +/– 27 GHz)
Max The maximum frequency of the instrument. (that is, a 27 GHz max freq instrument has a CF step
range of +/– 27 GHz)
Default Unit Hz
Status Bits/OPC
dependencies
non-overlapped
Initial S/W Revision A.07.00
CF à Signal (Replace)
Replaces the frequency of the selected signal with the Center Frequency (and Meters Freq since they are
the same). Amplitude values and Delta To Limit values will be shown as “---“ to indicate that those values
are undefined until the next scan/final measurement value.
Key Path
Freq
Remote Command
:CALCulate:MONitor:SLISt:REPLace:METer <integer>
Example CALC:MON:SLIS:REPL:MET 20 Replace Signal #20 with Center Freq
Notes If the signal list contains no data, an error is generated and this function cannot be performed.
If the selected signal is not in the list, an error is generated and this function cannot be performed.
Initial S/W Revision A.13.00
CF à List (Append)
Append the signal at the Center Frequency (and Meters Freq since they are the same) into the Frequency
Scan signal list. Amplitude values and Delta To Limit values will be shown as “---“ to indicate that those
EMI Receiver Mode Reference 755
