Keysight x-series User Reference Guide

8 Frequency Scan Measurement
Trace/ Detector
• Background: Update On, Display Off (this allows a trace to be blanked and continue to update “in the
background”)
Key Path
Trace/Detector
Notes The four states of this 1-of-N actually set two variables, Update and Display, to their four possible
combinations:
Trace On: Update and Display both On
View: Update Off and Display On
Blank: Update Off and Display Off
Background: Update On, Display Off
See the following tables, "Trace Update State (Remote Command Only)" on page 581 and "Trace
Display State (Remote Command Only)" on page 581, for details on the SCPI to control these two
variables.
Couplings Selecting a trace type (Clear Write, Trace Average, Max Hold, Min Hold) for a trace (pressing the key
or sending the equivalent remote command) puts the trace in Trace On (Update On and Display On),
even if that trace type was already selected.
Selecting a detector for a trace (pressing the key or sending a [:SENS]:DET:TRAC command) puts the
trace in Trace On (Update On and Display On), even if that detector was already selected.
Loading a trace from a file puts that trace in View regardless of the state it was in when it was saved;
as does being the target of a Copy or a participant in an Exchange.
When a View/ Blank selection is made, the menu returns to the previous menu.
Readback Text Trace On|View|Blank|Background
Initial S/W Revision A.07.00
Trace Update State (Remote Command Only)
Toggles the trace update state.
Remote Command
:TRACe[1]|2|3:FSCan:UPDate ON|OFF|1|0
:TRACe[1]|2|3:FSCan:UPDate?
Example FSC:TRAC2:UPD 0 Makes trace 2 inactive (stops updating).
FSC:TRAC2:UPD Query update state of trace 2.
Couplings Whenever you set Update to On for any trace, the Display is set to On for that trace.
Preset 1|0|0 (On for Trace 1; Off for 2–3)
State Saved Saved in instrument state
Initial S/W Revision A.07.00
Trace Display State (Remote Command Only)
Toggle the trace display state.
Remote Command
:TRACe[1]|2|3:FSCan:DISPlay ON|OFF|1|0
EMI Receiver Mode Reference 581
