Keysight x-series User Reference Guide

8 Frequency Scan Measurement
Meas Setup
Analog Demod Tune and Listen
The Analog Demod Tune and Listen key opens the Analog Demod menu that contains keys to turn the
demod function on and off and select modulation type.
When the function is on (set to AM, FM, or ΦM), the demodulated signal is fed to the analyzer’s speaker.
Muting and volume control functions are done through the standard Windows speaker volume control
interface.
Key Path
Meas Setup
Remote Command
[:SENSe]:FSCan:DEMod AM|FM|PM|OFF
[:SENSe]:FSCan:DEMod?
Example FSC:DEM AM Turns ON amplitude demodulation function.
FSC:DEM?
Dependencies Tune & Listen is only for Meters, which means that there will be no tune & Listen if any of the scan
sequences are running. When Tune & Listen is turned on, only Meter 1 will return the valid
measurement result. Meter 2 & 3 will return –1000dBm. Meter 2 & 3 will return valid measurement
results when Turn & Listen is turned off.
Couplings This key is grayed out when a scan sequence is running. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Preset OFF
State Saved Saved in instrument state.
Range AM|FM|PM|Off
Readback Text AM|FM|PM|Off
Backwards
Compatibility SCPI
:SENSe1|SENSe2:DEMod
[:SENSe]:DEMod
Backwards Compatibility
SCPI Notes
This command above is included for ESU compatibility. The suffix 1|2 is irrelevant to the
measurement, they are added solely for remote language compatibility. This SCPI is Meas Local and
Context Sensitive.
Initial S/W Revision A.07.00
AM
Pressing this key, when it is not selected, selects and activates the AM demodulation function. Pressing it a
second time branches to the AM Demod menu where AM demodulation settings can be adjusted.
Key Path
Meas Setup, Analog Demod
Example FSC:DEM AM Turns AM demodulation function ON.
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
EMI Receiver Mode Reference 501
