8 Frequency Scan Measurement
Meas Setup
Select Signal
Specifies the selected signal. The term “Selected signal” is used throughout this document to specify
which signal will be affected by the functions.
Key Path
Meas Setup, Signal List, Mark Signals
Notes Front panel only.
Dependencies Yes
Couplings When the signal list is cleared, this value will reset to 0.
Preset If the signal list is empty, =0
If the signal list is not empty, = number of peaks in signal list table
State Saved Saved in instrument state.
Min 0
Max Number of peaks in signal list table.
Initial S/W Revision A.07.00
Mark Signal
Marks the checkbox next to the selected signal.
Key Path
Meas Setup, Signal List, Mark Signals
Remote Command
:CALCulate:FSCan:SLISt:MARK:SIGNal <integer>
Example CALC:FSC:SLIS:MARK:SIGN 4 Mark signal #4.
Notes If the signal list contains no data, an error is generated and this function cannot be performed.
If the selected signal is not in the list, an error is generated and this function cannot be performed.
Dependencies This key is grayed out when a scan sequence is running. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Initial S/W Revision A.07.00
Mark Duplicates
This menu enables you to mark the signals that are duplicates. A signal is considered to be a duplicate if it
is within the width of the 3 dB RBW value. Signals cannot be duplicate unless they are measured using the
same 3 dB RBW.
Key Path
Meas Setup, Signal List, Mark Signals
Initial S/W Revision A.13.00
442 EMI Receiver Mode Reference
