10 Monitor Spectrum Measurement
Meas Setup
Key Path
Meas Setup, Limits, Edit
Remote Command
:CALCulate:LLINe[1]|2|...|6:BUILd TRACE1|TRACE2|TRACE3
Example CALC:LLIN2:BUIL TRACE1 Builds limit line 2 based on the data in trace 1. This will overwrite the
data in the table editor.
Notes Auto return to Edit menu.
Initial S/W Revision A.13.00
Offset
Enters a menu that allows you to offset the limit trace by a specified frequency, time, or amplitude. The
offsets will be immediately applied to the limit trace for display and failure calculation. The offset can also
be applied to the points in the limit line.
Key Path
Meas Setup, Limits, Edit
Initial S/W Revision A.13.00
X Offset
Offsets the limit trace by some specified frequency (for Frequency-based limit lines) or a time (for time-
based limit lines).
Key Path
Meas Setup, Limits, Edit, Offset
Remote Command
:CALCulate:LLINe[1]|2|...|6:OFFSet:X <freq>
:CALCulate:LLINe[1]|2|...|6:OFFSet:X?
Example CALC:LLIN:OFFS:X –50MHZ Sets the X axis offset to –50 MHz.
CALC:LLIN:OFFS:UPD Applies the X axis offset to all points in the limit line, then reset the X axis
offset to zero.
Preset 0 Hz if Limit X-Axis Unit is Frequency
0 S if Limit X-Axis Unit is Time
State Saved Saved in instrument state
Min –500 GHz
Max 500 GHz
Default Unit Determined by X axis scale.
Initial S/W Revision A.13.00
Y Offset
Offsets all segments in the limit line by some specified amplitude.
Key Path
Meas Setup, Limits, Edit, Offset
EMI Receiver Mode Reference 799
